Tractors > John Deere > 3330

John Deere 3330



John Deere 3330 tractor photo
1977 - 1980
Utility tractor
Series map:
2730
3330
3530
55.2kw
58.6kw
78.3kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Rosario, Argentina
Variants
3330HChigh-crop
John Deere 3330 Engine
John Deere 3.9L 4-cyl diesel
Fuel tank38.3 gal
145.0 L
Engine details ...
John Deere 3330 Transmission
8-speed
Transmission details ...
John Deere 3330 Power
Engine78.6 hp
58.6 kW
PTO (claimed)75.7 hp
56.4 kW
Mechanical
Two-wheel drive
Power steering
Hydraulic wet disc brakes
Open operator station.
Photos
No photos of the John Deere 3330 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Tractor hitch
Rear TypeII/I
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic
Rear PTO Type540
Dimensions & Tires
Wheelbase93.3 inches
236 cm
Weight10430 lbs
4731 kg
Front tire6.50x16
Rear tire15.5x38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps28
Batteries2
Battery volts6
Battery AH140
References
3330 references literature
Tractor 3330 published in 1979, by John Deere
