Production | |
Manufacturer | John Deere |
Utility tractor | |
Built in Augusta, Georgia, USA |
John Deere 5625 Engine | |
John Deere 4.5L 4-cyl diesel | |
Engine details ... |
John Deere 5625 Transmissions | |
9-speed partially synchronized | |
12-speed power shuttle | |
24-speed two-speed power shift | |
Transmission details ... |
John Deere 5625 Power | |
Engine (gross) | 99 hp 73.8 kW |
PTO (claimed) | 82 hp 61.1 kW |
PTO (tested) | 87.44 hp 65.2 kW |
Performance test details ... |
Mechanical | |
Four-wheel drive | |
Final drives | inboard planetary |
Differential lock | mechanical rear |
Power steering | |
Differential hydraulic wet disc brakes | |
Open operator station with two-post folding ROPS. Optional isolated flat-platform (IOOS). Cab available with air-conditioning. |
Photos | |
John Deere 5625 photos... |
Capacity | |
Fuel | 25 gal (straddle) 94.6 L |
  | 33.5 gal (IOOS/cab) 126.8 L |
Hydraulic system | 10.3 gal (9-speed) 39.0 L |
  | 11.5 gal (12-speed) 43.5 L |
  | 12 gal (24-speed) 45.4 L |
Front hubs | 0.74 qts*Each 0.7 L |
Front diff. | 4.8 qts 4.5 L |
Hydraulics | |
Type | open center |
Capacity | 10.3 gal (9-speed) 39.0 L |
  | 11.5 gal (12-speed) 43.5 L |
  | 12 gal (24-speed) 45.4 L |
Pressure | 2828 psi 195.0 bar |
Rear valves | 1 to 3 |
Mid valves | 0, 2 or 3 |
Pump flow | 18.4 gpm 69.6 lpm |
Total flow | 25 gpm 94.6 lpm |
Steering flow | 6.6 gpm 25.0 lpm |
Steering press. | 1957 psi 134.9 bar |
Tractor hitch | |
Rear Type | II/I |
Control | top-link draft sensing |
Rear lift (at 24"/610mm) | 3374 lbs 1530 kg |
Power Take-off (PTO) | |
Rear PTO | independent |
Clutch | dry disc |
  | electro-hydraulic wet disc (24-speed) |
Rear PTO Type | 540 |
  | 540/540E OptOptional |
  | 540/1000 *Optional field conversion kit. |
Engine RPM | 540@2400 |
  | 540E@1700 |
Dimensions & Tires | |
Wheelbase | 85.7 inches 217 cm |
Weight | 6030 to 7385 pounds |
Front tire | 11.2-24 |
Rear tire | 420/90R30 |
Full dimensions and tires ... |
John Deere 5625 attachments | |
front-end loader | |
Attachment details ... |
5625 Serial Numbers | |
2007 | 164002 |
FAQ: How to read a serial number table. |
Electrical | |
Ground | negative |
Charging system | alternator |
ROPS Charging amps | 70 |
Cab Charging amps | 90 |
  | 120 OptOptional |
Battery CCA | 750 |
Battery volts | 12 |
Battery Group | BCI 31 |
References | |
5025 Series Tractors published in 2007, by John Deere | |
Operator's Guide 5225, 5325, 5425 and 5625 Tractors (OMRE260579) published in 2007 |
