McCormick Intl C85 Max
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Utility tractor | |
| Built in Doncaster, England | |
| McCormick Intl C85 Max Engine | |
| Perkins 4.4L 4-cyl diesel | |
| Fuel tank | 27 gal 102.2 L |
 Engine details ... | |
| McCormick Intl C85 Max Transmissions | |
| 12-speed | |
| 24-speed | |
 Transmission details ... |
| McCormick Intl C85 Max Power | |
| Engine | 81.6 hp 60.8 kW |
| PTO (claimed) | 73 hp 54.4 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post ROPS. Cab optional. |
| Photos | |
| No photos of the McCormick Intl C85 Max are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2611 psi 180.0 bar |
| Valves | 2 to 4 |
| Pump flow | 13.8 gpm 52.2 lpm |
| Total flow | 21.7 gpm 82.1 lpm |
| Steering flow | 7.9 gpm 29.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 5732 lbs 2600 kg |
| 8157 lbsOptOptional 3700 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/750 |
| 540/1000 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 92.2 inches 234 cm |
| 4WD Wheelbase | 91.2 inches 231 cm |
| Weight | 6813 to 7343 pounds (4WD) |
| Front tire | 7.5-16 |
| Rear tire | 18.4/30 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| C Max Series published in 2006, by McCormick |
