Tractors > John Deere > 100F

John Deere 100F



John Deere 100F tractor photo
2008 - 2011
Orchard/Vineyard tractor
Goldoni built
Series map:
85F
100F
83.0hp
96.0hp
Production
DistributorJohn Deere
ManufacturerGoldoni
Orchard/Vineyard tractor
Built in Italy
John Deere 100F Engine
Detroit Diesel 2.9L 4-cyl diesel
Fuel tank16 gal
60.6 L
Engine details ...
John Deere 100F Transmissions
8-speed
16-speed
Transmission details ...
John Deere 100F Power
Engine96 hp
71.6 kW
PTO (claimed)83 hp
61.9 kW
Mechanical
Four-wheel drive
Steeringpower
Hydraulic wet disc brakes
Photos
No photos of the John Deere 100F are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2828 psi
195.0 bar
Valves2 or 3
Total flow10 gpm
37.9 lpm
Steering press.1958 psi
135.0 bar
Tractor hitch
Rear Type1/1N/2
Rear lift (at 24"/610mm)5,511 lbs
2499 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Dimensions & Tires
Wheelbase77 inches
195 cm
Weight5,556 lbs
2520 kg
Front tire240/70x16
Rear tire380/70x20
Full dimensions and tires ...
References
100F references literature
Specialty Tractors published in 2008, by John Deere
