John Deere 7330



John Deere 7330 tractor photo
2007 - 2011
7030 Small-Frame Series
Row-Crop tractor
Series map:
7230
7330
135.0hp
150.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
FactoriesWaterloo, Iowa, USA
 Mannheim, Baden-Württemberg, Germany
Original price$77,688 (2011)
In the spring of 2011, production of the 7330 was moved from Waterloo to Mannheim. The 110-inch rear axle option was dropped at that time. The 7330 was available with ROPS or a basic cab. Upgraded hydraulics and hitch were optional with ROPS but upgraded systems with a cab were only available on the 7330 Premium.
Variants
7330base tractor
7330 Premiumdeluxe tractor
7330 Premium High-Crophigh-clearance
John Deere 7330 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 7330 Transmissions
16-speed partial power shift
20-speed partial power shift
32-speed partial power shift
Transmission details ...
John Deere 7330 Power
Engine (gross)150 hp
111.9 kW
PTO (claimed)125 hp
93.2 kW
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Steeringhydrostatic power
Differential hydraulic wet disc brakes
Two-post Roll-Gard ROPS. Cab optional.
Photos
No photos of the John Deere 7330 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel66 gal
249.8 L
Hydraulic system13.7 gal
51.9 L
Front axle8.8 qts
8.3 L
Front hubs1.6 qts
1.5 L
Hydraulics
Typeconstant flow load sensing
 closed-center load sensing (optional ROPS)
Capacity13.7 gal
51.9 L
Pressure2900 psi
200.0 bar
Valves2 to 4
Pump flow21.1 gpm
79.9 lpm
 29 gpm (optional ROPS)
109.8 lpm
Tractor hitch
Rear TypeII
 3N/2
Controlposition control
 electronic lower-link (optional ROPS)
Rear lift (at 24"/610mm)8,800 lbs (II)
3991 kg
 8,200 lbs (3N/2)
3719 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540@1995
 1000@1995
Dimensions & Tires
Wheelbase104.3 inches
264 cm
Weight10800 to 12965 pounds
Front tire10.00-16
Rear tire18.4R38 (2WD)
Full dimensions and tires ...
7330 Serial Number Location
John Deere 7330 serial number location
Right side of main frame above front axle.
Electrical
Groundnegative
Charging systemalternator
Charging volts14
Battery volts12
References
7330 references literature
6030 and 7030 Series Tractors published in 2007, by John Deere
