Kubota L4150DTN
| Production |
| Manufacturer | Kubota
|
| Kubota L4150DTN Power |
| Engine | 50 hp
37.3 kW
|
| PTO (claimed) | 40 hp
29.8 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | power
|
| Mechanical wet disc brakes |
| Two-post ROPS with optional sunshade. |
| Photos |
| No photos of the Kubota L4150DTN are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 12.2 gal
46.2 L
|
| Hydraulic system | 10.6 gal
40.1 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 10.6 gal
40.1 L
|
| Pressure | 2500 psi
172.4 bar
|
| Valves | 0 or 1
|
| Pump flow | 9.0 gpm
34.1 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 3,525 lbs
1598 kg
|
| Rear lift (at 24"/610mm) | 2,650 lbs
1202 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/750
|
