Challenger MT525B
| | 2004 - 2011 |
|
| MT500B Series | | Row-Crop tractor |
|
Series map:
MT525B
MT535B
120.0hp
135.0hp
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Row-Crop tractor |
| Built in Beauvais, France |
| Original price | $81,819 (2009 AutoPower 2WD )
|
| $94,060 (2009 AutoPower 4WD )
|
| $103,431 (2009 CVT 4WD )
|
| Variants |
| 7465 | similar Massey Ferguson model
|
| 6465 | similar Massey Ferguson model
|
| Challenger MT525B Power |
| Engine | 120 hp
89.5 kW
|
| PTO (claimed) | 100 hp
74.6 kW
|
| Drawbar (tested) | 79.4 hp
59.2 kW
|
| PTO (tested) | 122.2 hp
91.1 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | electro-hydraulic front and rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| Cab standard with heat and air-conditioning. Optional pneumatic cab suspension and automatic temperature control. |
| Photos |
| No photos of the Challenger MT525B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 71 gal
268.7 L
|
| AP6 Hydraulic system | 18.5 gal
70.0 L
|
| CVT Hydraulic system | 26.4 gal
99.9 L
|
| Hydraulics |
| Type | closed center pressure flow compensated (PFC)
|
| AP6 Capacity | 18.5 gal
70.0 L
|
| CVT Capacity | 26.4 gal
99.9 L
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 2 to 4
|
| Total flow | 29 gpm
109.8 lpm
|
| Tractor hitch |
| Rear Type | II
|
| AP6 Rear lift (at 24"/610mm) | 7152 lbs
3244 kg
|
| CVT Rear lift (at 24"/610mm) | 10915 lbs
4951 kg
|
| Front Hitch | optional
|
| Front lift (at ends) | 6,600 lbs
2993 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/540E/1000 (1.375)
|
| Front PTO | independent OptOptional
|
| Front PTO Type | 1000 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 120
|
| | 150 OptOptional
|
| Batteries | 2
|
| Battery CCA | 420
|
| Battery volts | 12
|
| References |
 |
| Challenger MT500B Series published in 2008, by AGCO |
