Yanmar FX26


Yanmar FX26 tractor photo
1983 - 1987
Compact Utility tractor
Series map:
FX26
FX28
19.4kw
20.9kw
Production
ManufacturerYanmar
Compact Utility tractor
Variants
FX262WD
FX26D4WD
Yanmar FX26 Engine
Yanmar 1.6L 4-cyl diesel
Engine details ...
Yanmar FX26 Transmission
12-speed four-speed power shift
Transmission details ...
Yanmar FX26 Power
Engine26 hp
19.4 kW
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Open operator station.
Tractor hitch
Rear TypeI
Power Take-off (PTO)
Rear PTO Type540 (1.375)
FX26 Serial Numbers
Location:Left side of the tractor on the transmission housing.
Electrical
Groundnegative
Battery volts12
