Tractors > John Deere > 62

John Deere 62



John Deere 62 tractor photo
1937
Utility tractor
Series map:
62
10.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Moline, Illinois, USA
Total built78
Original price$450 (1937)
The John Deere model 62 tractor was resulted from years of research into a small tractor that would replace one or two horses. The 62 replaced the experimental model Y, although the 62 itself became the model L after less than one year of production. The 62 can be readily distinguished from the L by the "JD" below the radiator.
John Deere 62 Engine
Hercules 0.9L 2-cyl gasoline
Engine details ...
John Deere 62 Transmission
3-speed unsynchronized gear
Transmission details ...
John Deere 62 Power
Engine10 hp
7.5 kW
Mechanical
Two-wheel drive
Steeringmanual
Open operator station with steel pan seat.
Photos
John Deere 62
John Deere 62 photos...
Dimensions & Tires
Weight1,500 lbs
680 kg
Front tire4x15
Rear tire6x22
Full dimensions and tires ...
62 Serial Numbers
Location:Right side of rear axle
1937621001
Final621078

FAQ: How to read a serial number table.
