John Deere 2355N


John Deere 2355N tractor photo
1987 - 1994
55 Utility Series
Orchard/Vineyard tractor
Series map:
2355N
2855N
65.0hp
88.9hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Variants
2355utility tractor
John Deere 2355N Engine
John Deere 2.9L 3-cyl diesel
Fuel tank17.7 gal
67.0 L
Engine details ...
John Deere 2355N Transmissions
8-speed collar shift
8-speed partially synchronized
16-speed partial power shift
12-speed
Transmission details ...
John Deere 2355N Power
Engine65 hp
48.5 kW
PTO (claimed)55 hp
41.0 kW
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Steeringpower
Hydraulic disc brakes
Telescoping two-post Roll-Gard ROPS.
Photos
No photos of the John Deere 2355N are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Pressure2320 psi
160.0 bar
Pump flow12 gpm
45.4 lpm
Power Take-off (PTO)
Rear PTOlive
 independent (TSS)
Clutchwet disc
Rear PTO Type540
Dimensions & Tires
Front tire6.5x16
Rear tire14.9x24
Full dimensions and tires ...
2355N Serial Numbers
1987600000
1988624800
1989654199
199068555
1991717916
1992746510
1993775104
1994803700

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery CCA610
Battery volts12
References
2355N references literature
40 to 100 HP Tractors Product Information Handbook published in 1991, by John Deere
Special Power published in 1990, by John Deere
Special Dimension Tractors published in 1992, by John Deere
The 1991 Long Green Line Agricultural Equipment Review published by John Deere
