Tractors > John Deere > 1550

John Deere 1550



John Deere 1550 tractor photo
1987 - 1994
Utility tractor
Series map:
1350
1550
1750
28.0kw
32.4kw
37.3kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 1550 Engine
John Deere 2.9L 3-cyl diesel
Fuel tank20.6 gal
78.0 L
Engine details ...
John Deere 1550 Transmissions
8-speed synchromesh
16-speed
12-speed creeper
Transmission details ...
John Deere 1550 Power
Engine43.4 hp
32.4 kW
Mechanical
Two- or four-wheel drive
Steeringmanual
 hydrostatic power *Available with four-wheel drive.
Hydraulic wet disc brakes
ROPS. Optional MC1 cab, or CC2 cab after 1990.
Photos
No photos of the John Deere 1550 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2756 psi
190.0 bar
Pump flow5.8 gpm
22.0 lpm
 11.6 gpmOptOptional
43.9 lpm
Tractor hitch
Rear TypeII/I
Rear lift5283 lbs
2396 kg
Power Take-off (PTO)
Rear PTO Type540
 540/1000
Dimensions & Tires
2WD Wheelbase80.7 inches
204 cm
4WD Wheelbase81 inches
205 cm
Weight5468 to 6691 pounds
Front tire6.50-16
Rear tire12.4-36 (2WD)
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Batteries2
Battery volts12
Battery AH55
References
1550 references literature
Traktor 1550 published in 1987, by John Deere
