ATC Terratrac GT-30


ATC Terratrac GT-30 tractor photo
1951 - 1954
Agricultural Crawler tractor
Production
ManufacturerATC
Agricultural Crawler tractor
Built in Churubusco, Indiana, USA
ATC GT-30 Engine
Continental 2.3L 4-cyl gasoline
Fuel tank10 gal
37.9 L
Engine details ...
ATC GT-30 Power
Drawbar (claimed)24 hp
17.9 kW
Belt (claimed)30 hp
22.4 kW
Drawbar (tested)25.16 hp
18.8 kW
Belt (tested)30.41 hp
22.7 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringmanual
Mechanical contracting band brakes
Open operator station.
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Engine RPM540@1622
Dimensions & Tracks
Weight3400 to 4471 pounds
10-inch tracks
Full dimensions and tracks ...
GT-30 Serial Numbers
195110001
195210488
195311197
195411359
Final11463

FAQ: How to read a serial number table.
Belt Pulley
Diameter8.5 inches
21 cm
Width6.5 inches
16 cm
RPM1192
Speed2652 ft/min
808.33 meters/min
References
Terratrac GT-30 references literature
New TerraTrac GT 30 published in 1951, by American Tractor Corporation
