Hinomoto NX200
| | 1993 - 1995 |
| NX Series | | Compact Utility tractor | | Kubota built |
|
Series map:
NX200
NX220
14.7kw
16.2kw
Note: the Hinomoto model NX200 is the same as the Kubota GL200. The following data is from the GL200 listing. |
| Production |
| Distributor | Hinomoto
|
| Manufacturer | Kubota
|
| Compact Utility tractor |
| Hinomoto NX200 Power |
| Engine | 19.7 hp
14.7 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Mechanical wet disc brakes |
| Two-post ROPS. Cab optional. |
| Power Take-off (PTO) |
| Rear PTO Type | 546/772/947/1254 (1.375)
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on September 28, 2017 |
