Hinomoto E25


Hinomoto E25 tractor photo
1977 - 1979
Compact Utility tractor
Production
ManufacturerHinomoto
Compact Utility tractor
Built in Japan
Variants
E25D4WD
Hinomoto E25 Engine
Toyosha 1.3L 2-cyl diesel
Engine details ...
Hinomoto E25 Power
Engine25 hp
18.6 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Photos
No photos of the Hinomoto E25 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Engine RPM580@2500
 817@2500
 1420@2500
Dimensions & Tires
Wheelbase59.1 inches
150 cm
Weight1896 lbs
860 kg
Front tire4.00-15
Rear tire9.5/9-24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
E25 references literature
E25 published by Hinomoto
