Gibson I


Gibson I tractor photo
1948 - 1952
Row-Crop tractor
Production
ManufacturerGibson
Row-Crop tractor
Built in Longmont, Colorado, USA
Variants
Itricycle-front
IFAadjustable wide-front
IFSstandard front
Gibson I Engine
Hercules 3.9L 6-cyl gasoline
Fuel tank20 gal
75.7 L
Engine details ...
Gibson I Power
Plows2-3
Drawbar (tested)29.1 hp
21.7 kW
PTO (tested)36.82 hp
27.5 kW
Belt (tested)41.03 hp
30.6 kW
Performance test details ...
Mechanical
Two-wheel drive
Final drivesbull gear
Manual steering
Mechanical band brakes
Open operator station.
Photos
No photos of the Gibson I are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear PTOlive
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase94 inches
238 cm
Weight4000 to 4512 pounds
Front tire5.50-16
Rear tire10-38
Full dimensions and tires ...
Belt Pulley
Diameter9.2 inches
23 cm
Width7.5 inches
19 cm
RPM1487
Speed3539 ft/min
1078.69 meters/min
References
I references literature
Gibson Tractors - Durability, lower operating costs, plus extra power. published in 1948
