Farmall 1066 Tests
|
|
Note: the Farmall model 1066 is the same as the International Harvester 1066. The following data is from the 1066 listing. |
| Tractor Tests | |
| NTTL 1081: diesel Torque Amplifier 2WD | |
| NTTL 1083: diesel hydrostatic 2WD | |
| NTTL 1124: diesel gear 2WD |
| Nebraska Tractor Test 1081 | |||
| |||
| Nebraska Tractor Test 1081 | |
| Diesel Torque Amplifier 2WD October 1 - 21, 1971 Link: Nebraska Tractor Test 1081 file | |
| PTO performance | |
| Power at rated engine speed | 116.23 hp 86.7 kW |
| Fuel use | 7.7 gal/hour 29.1 l/hour |
| Power at rated PTO speed | 112.18 hp 83.7 kW |
| Fuel use | 6.8 gal/hour 25.7 l/hour |
| Drawbar performance | |
| Max power | 100.5 hp 74.9 kW |
| Fuel use | 7.6 gal/hour 28.8 l/hour |
| Gear 1-Hi-TA used for power test. | |
| Max pull | 11625 lbs 5273 kg |
| Gear 3-Lo-TA used for pull test. | |
| Nebraska Tractor Test 1083 | |||
| |||
| Nebraska Tractor Test 1083 | |
| Diesel hydrostatic 2WD October 7 - 25, 1971 Link: Nebraska Tractor Test 1083 file | |
| PTO performance | |
| Power at rated engine speed | 113.58 hp 84.7 kW |
| Fuel use | 7.9 gal/hour 29.9 l/hour |
| Power at rated PTO speed | 109.32 hp 81.5 kW |
| Fuel use | 7.0 gal/hour 26.5 l/hour |
| Drawbar performance | |
| Max power | 84.88 hp 63.3 kW |
| Fuel use | 8.0 gal/hour 30.3 l/hour |
| Gear 5.4 MPH used for power test. | |
| Max pull | 9576 lbs 4343 kg |
| Gear 3.1 MPH used for pull test. | |
| Nebraska Tractor Test 1124 | |||
| |||
| Nebraska Tractor Test 1124 | |
| Diesel gear 2WD April 17 - 27, 1973 Link: Nebraska Tractor Test 1124 file | |
| PTO performance | |
| Power at rated engine speed | 125.68 hp 93.7 kW |
| Fuel use | 8.4 gal/hour 31.8 l/hour |
| Power at rated PTO speed | 119.2 hp 88.9 kW |
| Fuel use | 7.3 gal/hour 27.6 l/hour |
| Drawbar performance | |
| Max power | 105.95 hp 79.0 kW |
| Fuel use | 8.3 gal/hour 31.4 l/hour |
| Gear 1-Hi-TA used for power test. | |
| Max pull | 13000 lbs 5896 kg |
| Gear 2-Lo-Direct used for pull test. | |
