Farmall 966 Tests
|
|
Note: the Farmall model 966 is the same as the International Harvester 966. The following data is from the 966 listing. |
| Tractor Tests | |
| NTTL 1082: 2400rpm diesel gear/TA 2WD | |
| NTTL 1095: diesel hydrostatic 2WD | |
| NTTL 1123: 2600rpm diesel gear/TA 2WD |
| Nebraska Tractor Test 1082 | |||
| |||
| Nebraska Tractor Test 1082 | |
| 2400rpm diesel gear/TA 2WD October 5 - 19, 1971 Link: Nebraska Tractor Test 1082 file | |
| PTO performance | |
| Power at rated engine speed | 96.04 hp 71.6 kW |
| Fuel use | 6.5 gal/hour 24.6 l/hour |
| Power at rated PTO speed | 93.5 hp 69.7 kW |
| Fuel use | 5.9 gal/hour 22.3 l/hour |
| Drawbar performance | |
| Max power | 80.4 hp 60.0 kW |
| Fuel use | 6.4 gal/hour 24.2 l/hour |
| Gear 1-Hi-TA used for power test. | |
| Max pull | 10,041 lbs 4554 kg |
| Gear 3-Lo-TA used for pull test. | |
| Nebraska Tractor Test 1095 | |||
| |||
| Nebraska Tractor Test 1095 | |
| Diesel hydrostatic 2WD April 28 - May 12, 1972 Link: Nebraska Tractor Test 1095 file | |
| PTO performance | |
| Power at rated engine speed | 91.38 hp 68.1 kW |
| Fuel use | 7.2 gal/hour 27.3 l/hour |
| Power at rated PTO speed | 88.29 hp 65.8 kW |
| Fuel use | 6.4 gal/hour 24.2 l/hour |
| Drawbar performance | |
| Max power | 68.08 hp 50.8 kW |
| Fuel use | 7.1 gal/hour 26.9 l/hour |
| Gear 5.4 MPH used for power test. | |
| Max pull | 8,909 lbs 4041 kg |
| Gear 2.77 MPH used for pull test. | |
| Nebraska Tractor Test 1123 | |||
| |||
| Nebraska Tractor Test 1123 | |
| 2600rpm diesel gear/TA 2WD April 20 - May 17, 1973 Link: Nebraska Tractor Test 1123 file | |
| PTO performance | |
| Power at rated engine speed | 100.80 hp 75.2 kW |
| Fuel use | 6.9 gal/hour 26.1 l/hour |
| Power at rated PTO speed | 101.52 hp 75.7 kW |
| Fuel use | 6.5 gal/hour 24.6 l/hour |
| Drawbar performance | |
| Max power | 85.21 hp 63.5 kW |
| Fuel use | 6.9 gal/hour 26.1 l/hour |
| Gear 1-Hi-TA used for power test. | |
| Max pull | 10,036 lbs 4552 kg |
| Gear 3-Lo-TA used for pull test. | |
