Deutz-Fahr Argotron L 730


Deutz-Fahr Argotron L 730 tractor photo
2010 - 2013
Agrotron L Series
Row-Crop tractor
Series map:
Argotron L 710
Argotron L 730
139.0kw
157.0kw
Production
ManufacturerDeutz-Fahr (a part of SAME)
Row-Crop tractor
Deutz-Fahr Argotron L 730 Engine
Deutz 7.1L 6-cyl diesel
Fuel tank100.4 gal
380.0 L
Engine details ...
Deutz-Fahr Argotron L 730 Transmissions
24-speed 12-speed power shift
33-speed creeper
Transmission details ...
Deutz-Fahr Argotron L 730 Power
Engine (gross)210.5 hp
157.0 kW
Engine (max)217.3 hp
162.0 kW
Mechanical
Four-wheel drive
Differential lockeletro-hydraulic front and rear
Power steering
Wet disc brakes
Trailer brakeshydraulic Opt
Cab standard with air-conditioning.
Photos
No photos of the Deutz-Fahr Argotron L 730 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2611 psi
180.0 bar
Rear valves5
Front valves2 Opt
Pump flow29.9 gpm
113.2 lpm
Steering flow9.8 gpm
37.1 lpm
Tractor hitch
Rear lift22046 lbs
10000 kg
Front lift8818 lbs
3999 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1650
 1000@2136
Front PTOindependent Opt
Clutchelectro-hydraulic wet disc
Front PTO Type1000 (1.375)
Engine RPM1000@2043
Dimensions & Tires
Wheelbase117.5 inches
298 cm
Weight18118 lbs
8218 kg
Front tire540/65R34
Rear tire650/65R42
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Argotron L 730 references literature
Agrotron L published in 2011, by Deutz-Fahr
