Deutz-Fahr Argotron L 710
|
|
| Production | |
| Manufacturer | Deutz-Fahr (a part of SAME) |
| Row-Crop tractor | |
| Deutz-Fahr Argotron L 710 Engine | |
| Deutz 7.1L 6-cyl diesel | |
| Fuel tank | 100.4 gal 380.0 L |
 Engine details ... | |
| Deutz-Fahr Argotron L 710 Transmissions | |
| 24-speed 12-speed power shift | |
| 33-speed creeper | |
 Transmission details ... |
| Deutz-Fahr Argotron L 710 Power | |
| Engine (gross) | 186.4 hp 139.0 kW |
| Engine (max) | 194.5 hp 145.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | eletro-hydraulic front and rear |
| Power steering | |
| Wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Deutz-Fahr Argotron L 710 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Rear valves | 5 |
| Front valves | 2 OptOptional |
| Pump flow | 29.9 gpm 113.2 lpm |
| Steering flow | 9.8 gpm 37.1 lpm |
| Tractor hitch | |
| Rear lift | 22046 lbs 10000 kg |
| Front lift | 8818 lbs 3999 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1650 |
| 1000@2136 | |
| Front PTO | independent OptOptional |
| Clutch | electro-hydraulic wet disc |
| Front PTO Type | 1000 (1.375) |
| Engine RPM | 1000@2043 |
| Dimensions & Tires | |
| Wheelbase | 117.5 inches 298 cm |
| Weight | 18118 lbs 8218 kg |
| Front tire | 540/65R34 |
| Rear tire | 650/65R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Agrotron L published in 2011, by Deutz-Fahr |
