Renault 95-14 TX
|
|
| Production | |
| Manufacturer | Renault |
| Row-Crop tractor | |
| Variants | |
| 95-12 | 2WD |
| Renault 95-14 TX Engine | |
| MWM 4.2L 4-cyl diesel | |
| Fuel tank | 33 gal 124.9 L |
 Engine details ... | |
| Renault 95-14 TX Transmissions | |
| 12-speed synchronized | |
| 16-speed creeper | |
 Transmission details ... |
| Renault 95-14 TX Power | |
| Engine | 83.1 hp 62.0 kW |
| PTO (claimed) | 77.8 hp 58.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic dry disc brakes | |
| Cab standard with heat. |
| Photos | |
| No photos of the Renault 95-14 TX are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Total flow | 11.3 gpm 42.8 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 9375 lbs 4252 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | organic |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 666@2430 |
| 1142@2430 | |
| Dimensions & Tires | |
| Wheelbase | 97.6 inches 247 cm |
| Weight | 10174 lbs 4614 kg |
| Front tire | 14.9-24 |
| Rear tire | 16.9-34 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging amps | 50 |
| Battery volts | 12 |
| Battery AH | 90 |
| References | |
 | |
| Renault Serie TX |
