Landini 5830
Series map:
5830
6030
37.3kw
41.8kw
Note: the Landini model 5830 is the same as the Massey Ferguson 254. The following data is from the 254 listing. |
| Production |
| Manufacturer | Landini
|
| Original price | $20,600 (1987)
|
| Landini 5830 Power |
| Engine | 50 hp
37.3 kW
|
| PTO (claimed) | 42 hp
31.3 kW
|
| Drawbar (tested) | 33.97 hp
25.3 kW
|
| PTO (tested) | 43.36 hp
32.3 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Differential lock | pedal-operated
|
| Steering | hydrostatic power
|
| Differential mechanical dry disc brakes |
| Two-post ROPS. |
| Photos |
| No photos of the Landini 5830 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open
|
| Pressure | 2250 psi
155.1 bar
|
| Valves | 2
|
| Pump flow | 9.2 gpm
34.8 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | draft and position control
|
| Rear lift (at ends) | 5,070 lbs
2299 kg
|
| Rear lift (at 24"/610mm) | 3,670 lbs
1664 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/ground
|
| Front PTO | direct-drive
|
| Front PTO Type | 2250
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 9, 2015 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
