Valtra C120e EcoPower
|
|
| Production | |
| Manufacturer | Valtra |
| Row-Crop tractor | |
| Valtra C120e Engine | |
| SisuDiesel 4.4L 4-cyl diesel | |
| Fuel tank | 47.6 gal 180.2 L |
 Engine details ... | |
| Valtra C120e Transmission | |
| 36-speed power shift | |
 Transmission details ... |
| Valtra C120e Power | |
| Engine | 120 hp 89.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | automatic |
| Power steering | |
| Wet disc brakes | |
| Cab standard with optional air-conditioning. | |
| Photos | |
| No photos of the Valtra C120e are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | load sensing |
| Pressure | 2843 psi 196.0 bar |
| Valves | 2 to 4 |
| Total flow | 21.7 gpm 82.1 lpm |
| Tractor hitch | |
| Rear Type | 3 |
| Rear lift (at ends) | 15,870 lbs 7198 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| 540/540E | |
| 1000/540E | |
| 1000 | |
| Engine RPM | 540@1648 |
| 540E@1539 | |
| 1000@1750 | |
| Dimensions & Tires | |
| Wheelbase | 95.1 inches 241 cm |
| Weight | 10,690 lbs 4848 kg |
| Front tire | 14.9R28 |
| Rear tire | 18.4R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery volts | 12 |
| Battery AH | 174 |
| References | |
 | |
| C Series published by Valtra |
