Kubota L3000
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Variants | |
| L3000F | 2WD |
| L3000DT | 4WD |
| Kubota L3000 Engine | |
| Kubota 1.5L 3-cyl diesel | |
| Fuel tank | 8.2 gal 31.0 L |
 Engine details ... | |
| Kubota L3000 Transmission | |
| 8-speed sliding gear | |
 Transmission details ... |
| Kubota L3000 Power | |
| Engine (gross) | 32.1 hp 23.9 kW |
| PTO (claimed) | 27.5 hp 20.5 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post ROPS. | |
| Photos | |
 | |
 Kubota L3000 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2205 psi 152.0 bar |
| Total flow | 6.9 gpm 26.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 1985 lbs 900 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Clutch | dual-stage dry disc |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| 2WD Wheelbase | 62.4 inches 158 cm |
| 4WD Wheelbase | 62.8 inches 159 cm |
| Weight | 2183 to 2425 pounds |
| Front tire | 5.00-15 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| Kubota L3000 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery CCA | 490 |
| Battery volts | 12 |
| References | |
 | |
| L2600/L3000 published in 2000, by Kubota | |
| L2600/L3000/L4300 Basic Tractor Series published in 2002, by Kubota |
