John Deere 2750 High-Clearance


John Deere 2750 High-Clearance tractor photo
1983 - 1988
2050 Series
High-Clearance tractor
Production
ManufacturerJohn Deere
High-Clearance tractor
Variants
2750utility chassis
2750 High-Clearancehigh-crop
2750 Low-Profileorchard
John Deere 2750 High-Clearance Engine
John Deere 3.9L 4-cyl diesel
Fuel tank26 gal
98.4 L
Engine details ...
John Deere 2750 High-Clearance Power
PTO (claimed)75 hp
55.9 kW
Mechanical
Four-wheel drive
Differential lockrear standard
Steeringhydrostatic power
Differential hydraulic wet disc brakes
Two-post ROPS.
Photos
No photos of the John Deere 2750 High-Clearance are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Rear valves1 or 2
Pump flow23 gpm
87.1 lpm
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 540/1000 (optional)
Dimensions & Tires
Weight7,880 lbs
3574 kg
Front tire13.6-38
Rear tire13.6-46
Full dimensions and tires ...
2750 High-Clearance Serial Numbers
Location:Right side of main tractor frame, above front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery volts12
References
2750 High-Clearance references literature
Tractors 45 to 85 HP published in 1984, by John Deere
Tractors Hi-Crop, Low-Profile, Narrow- and Wide-Tread published in 1985, by John Deere
