Tractors > John Deere > 840

John Deere 840



John Deere 840 tractor photo
1976 - 1986
Utility tractor
Series map:
840
940
28.0kw
32.0kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 840 Engine
John Deere 2.9L 3-cyl diesel
Engine details ...
John Deere 840 Transmissions
8-speed collar shift
16-speed two-speed power shift
Transmission details ...
John Deere 840 Power
Engine37.5 hp
28.0 kW
PTO (claimed)33.5 hp
25.0 kW
Mechanical
Two-wheel drive
Final drivesplanetary
Manual steering
Hydraulic wet disc brakes
Four-post ROPS.
Photos
No photos of the John Deere 840 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel20.6 gal
78.0 L
Hydraulic system10.8 gal
40.9 L
Hydraulics
Typeclosed center
Capacity10.8 gal
40.9 L
Pump flow6.1 gpm
23.1 lpm
Tractor hitch
Rear TypeII/I
Rear lift4878 lbs
2212 kg
Power Take-off (PTO)
Rear PTOlive
 independent OptOptional
Clutchdry disc
 wet disc *Optional, independent PTO
Rear PTO Type540
Engine RPM540@2400
Front PTOoptional
Front PTO Type1000
Engine RPM1000@2070
Dimensions & Tires
Wheelbase74.4 inches
188 cm
Weight5004 lbs
2269 kg
Front tire6.50-16
Rear tire12.4-32
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps33
Batteries2
Battery volts12
References
840 references literature
Der Neue Traktor 840 published in 1979, by John Deere
