Cub Cadet 7000
| | 1998 - 2003 |
| 7000 Series | | Sub-Compact Utility tractor |
|
Series map:
7000
7200
20.0hp
20.0hp
| Production |
| Manufacturer | Cub Cadet
|
| Sub-Compact Utility tractor |
| Original price was $11,400 in 2003 |
| Cub Cadet 7000 Power |
| Engine | 20 hp
14.9 kW
|
| PTO (claimed) | 17.5 hp
13.0 kW
|
| Mechanical |
| Two-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Mechanical dry shoe brakes |
| Two-post folding ROPS. |
| Hydraulics |
| Type | open center
|
| Pressure | 2133 psi
147.1 bar
|
| Pump flow | 5.8 gpm
22.0 lpm
|
| Total flow | 9.2 gpm
34.8 lpm
|
| Steering flow | 3.4 gpm
12.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 1400 lbs
635 kg
|
| Rear lift (at 24"/610mm) | 980 lbs
444 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2356
|
| Mid PTO | live OptOptional
|
| Mid PTO Type | 2000 (1.0)
|
| Engine RPM | 2000@2470
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Series 7000 Tractors published in 1998, by Cub Cadet |
| Series 7000 Compact Tractors published in 1999, by Cub Cadet |
| Series 7000 Tractors published in 2001, by Cub Cadet |
| Owner's Manual Series 7000 Compact Tractor (770-0910A) |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 30, 2023 |
