Challenger MT325B
|
|
| Production | |
| Manufacturer | Challenger (a part of AGCO) |
| Utility tractor | |
| Challenger MT325B Engine | |
| Challenger 3.3L 3-cyl diesel | |
| Fuel tank | 29 gal 109.8 L |
 Engine details ... | |
| Challenger MT325B Transmissions | |
| 12-speed synchronized shuttle | |
| 12-speed power shuttle | |
 Transmission details ... |
| Challenger MT325B Power | |
| Engine (gross) | 68 hp 50.7 kW |
| PTO (claimed) | 55 hp 41.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | electro-hydraulic |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Two-post folding ROPS. Cab with air-conditioning optional. | |
| Photos | |
| No photos of the Challenger MT325B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2755 psi 190.0 bar |
| Rear valves | 2 or 3 |
| Mid valves | 0 or 2 |
| SCV flow | 15.8 gpm 59.8 lpm |
| Total flow | 22.4 gpm 84.8 lpm |
| Tractor hitch | |
| Rear Type | I/II |
| Control | position and draft control |
| Rear lift (at ends) | 5500 lbs 2494 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540 |
| 540/540E *Optional. | |
| Dimensions & Tires | |
| Wheelbase | 82.7 inches 210 cm |
| Weight | 5291 to 7716 pounds |
 Full dimensions and tires ... | |
| Challenger MT325B attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 80 |
| Battery CCA | 675 |
| Battery volts | 12 |
| References | |
 | |
| Challenger MT300B Series published in 2006, by AGCO | |
| Challenger Specialty Wheel Tractors published in 2007 |
