McCormick Intl MTX140
|
|
| Production | |
| Manufacturer | McCormick Intl |
| Row-Crop tractor | |
| Built in Doncaster, England | |
| McCormick Intl MTX140 Engine | |
| Perkins 6.0L 6-cyl diesel | |
| Fuel tank | 70 gal 264.9 L |
 Engine details ... | |
| McCormick Intl MTX140 Transmissions | |
| 16-speed four-speed power shift | |
| 32-speed creeper | |
 Transmission details ... |
| McCormick Intl MTX140 Power | |
| Engine | 145 hp 108.1 kW |
| Drawbar (claimed) | 110 hp 82.0 kW |
| PTO (claimed) | 127 hp 94.7 kW |
| Drawbar (tested) | 111.2 hp 82.9 kW |
| PTO (tested) | 127.8 hp 95.3 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostaic power |
| Wet disc brakes | |
| Photos | |
| No photos of the McCormick Intl MTX140 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | pressure flow compensating |
| Pump flow | 28.8 gpm 109.0 lpm |
| SCV flow | 25.1 gpm 95.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | electronic lower link draft sensing |
| Rear lift (at 24"/610mm) | 10180 lbs 4617 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@1877 |
| 1000@2200 | |
| Dimensions & Tires | |
| Wheelbase | 106.3 inches 270 cm |
| Weight | 12130 to 14205 pounds |
| Front tire | 16.9R28 |
| Rear tire | 20.8R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 95 |
| Battery volts | 12 |
