Tractors > Challenger > MT865

Challenger MT865



Challenger MT865 tractor photo
2002 - 2004
MT800 Series
Agricultural Crawler tractor
Series map:
MT855
MT865
450.0hp
500.0hp
Production
ManufacturerChallenger (a part of AGCO)
Agricultural Crawler tractor
Built in USA
Challenger MT865 Engine
Caterpillar 15.8L 6-cyl diesel
Engine details ...
Challenger MT865 Transmission
16-speed full power shift
Transmission details ...
Challenger MT865 Power
Engine (gross)500 hp
372.9 kW
PTO (claimed)416 hp
310.2 kW
Drawbar (tested)378.75 hp
282.4 kW
PTO (tested)523.60 hp
390.4 kW
Performance test details ...
Mechanical
Drivecrawler
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Challenger MT865 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel330 gal
1249.0 L
Hydraulic system70 gal
264.9 L
Hydraulics
Typeclosed center load sensing
Capacity70 gal
264.9 L
Pressure2900 psi
200.0 bar
Rear valves4 to 6
Pump flow43.5 gpm
164.6 lpm
 59 gpmOptOptional
223.3 lpm
SCV flow30 gpm
113.6 lpm
Tractor hitch
Rear TypeIVN
Rear lift19500 lbs
8845 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Wheelbase118.1 inches
299 cm
Weight41000 lbs
18597 kg
18-inch tracks
Full dimensions and tracks ...
MT865 Serial Numbers
Location:Serial number plate on the left side of the tractor frame.
2002BDS20000
2003BDS30000
2004BDS40000

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps160
Batteries4
Battery volts12
References
MT865 references literature
MT800 Series published in 2002, by AGCO
