Challenger MT835



Challenger MT835 tractor photo
2002 - 2004
MT800 Series
Agricultural Crawler tractor
Series map:
MT835
MT845
340.0hp
380.0hp
Production
ManufacturerChallenger (a part of AGCO)
Agricultural Crawler tractor
Built in USA
Challenger MT835 Engine
Caterpillar 11.9L 6-cyl diesel
Engine details ...
Challenger MT835 Transmission
16-speed full power shift
Transmission details ...
Challenger MT835 Power
Engine (gross)340 hp
253.5 kW
PTO (claimed)275 hp
205.1 kW
Drawbar (tested)263.26 hp
196.3 kW
PTO (tested)357.91 hp
266.9 kW
Performance test details ...
Mechanical
Drivecrawler
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Challenger MT835 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel305 gal
1154.4 L
 330 galOptOptional
1249.0 L
Hydraulic system70 gal
264.9 L
Hydraulics
Typeclosed center load sensing
Capacity70 gal
264.9 L
Pressure2900 psi
200.0 bar
Rear valves4 to 6
Pump flow43.5 gpm
164.6 lpm
 59 gpmOptOptional
223.3 lpm
SCV flow30 gpm
113.6 lpm
Tractor hitch
Rear TypeIVN
Rear lift19500 lbs
8845 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Wheelbase118.1 inches
299 cm
Weight40000 lbs
18144 kg
18-inch tracks
Full dimensions and tracks ...
MT835 Serial Numbers
Location:Serial number plate on the left side of the tractor frame.
2002BAM20000
2003BAM30000
2004BAM40000

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps160
Batteries3
Battery volts12
References
MT835 references literature
MT800 Series published in 2002, by AGCO
