| | 2002 - 2003 |
| MT500 Series | | Row-Crop tractor |
|
Series map:
MT545
MT565
133.3hp*
161.1hp*
*Estimated engine power for comparison only.
| Transmission options |
| 18-speed full power shift |
| 32-speed partial power shift |
| Transmission |
| Type | full power shift
|
| Gears | 18 forward and 6 reverse
|
| Clutch | wet disc
|
| Speeds |
|
| Transmission |
| Transmission | AutoPower IV
|
| Type | partial power shift
|
| Gears | 32 forward and reverse
|
| Clutch | hydraulic wet disc
|
| Four synchronized gears (1-4) in two synchronized ranges (low/high) with a four-speed (A-D) power shift on the left-hand power shuttle lever. |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on January 20, 2017 |
