Challenger MT545B
| | 2004 - 2011 |
|
| MT500B Series | | Row-Crop tractor |
|
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Row-Crop tractor |
| Built in Beauvais, France |
| The Challenger MT545B is similar to the Massey Ferguson 7480. |
| Variants |
| 6480 | similar Massey Ferguson model
|
| 7480 | similar Massey Ferguson model
|
| Challenger MT545B Power |
| Engine | 143 hp
106.6 kW
|
| PTO (claimed) | 115 hp
85.8 kW
|
| Drawbar (tested) | 100.4 hp
74.9 kW
|
| PTO (tested) | 125.7 hp
93.7 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic front and rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| Cab standard with heat and A/C. Optional pneumatic cab suspension and automatic climate control. |
| Photos |
| No photos of the Challenger MT545B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 71 gal
268.7 L
|
| Hydraulic system | 18.5 gal (AutoPower)
70.0 L
|
| | 26.4 gal (CVT)
99.9 L
|
| Hydraulics |
| Type | closed center pressure flow compensating (PFC)
|
| Capacity | 18.5 gal (AutoPower)
70.0 L
|
| | 26.4 gal (CVT)
99.9 L
|
| Pressure | 2900 psi
200.0 bar
|
| Rear valves | 2 to 4
|
| Total flow | 29 gpm
109.8 lpm
|
| Tractor hitch |
| Rear Type | II/III
|
| Rear lift (at 24"/610mm) | 9,391 lbs
4259 kg
|
| | 11,200 lbs (CVT)
5080 kg
|
| Front Hitch | optional
|
| Front lift | 5,500 lbs
2494 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet disc
|
| Rear PTO Type | 540/1000 (standard)
|
| | 540/540E/1000 OptOptional
|
| Engine RPM | 540@1980
|
| | 540E@1533
|
| | 1000@2000
|
| | 1000E@1548
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 120
|
| Batteries | 2
|
| Battery CCA | 420
|
| Battery volts | 12
|
| References |
 |
| Challenger MT500B AutoPower IV Product Information Guide published in 2004, by AGCO |
| Challenger MT500B Series published in 2005, by AGCO |
| Challenger MT500B TECHstar CVT Product Information Guide published in 2004, by AGCO |
| Challenger Specialty Wheel Tractors published in 2007 |
