Challenger MT545B Tests
|
|
| Tractor Tests | |
| OECD 2225: diesel AutoPower IV 4WD | |
| OECD 2195: diesel CVT 4WD |
| OCED Tractor Test 2225 | |||
| |||
| OCED Tractor Test 2225 | |
| Diesel AutoPower IV 4WD April 2004 - June 2004, Link: OCED Tractor Test 2225 file | |
| PTO performance | |
| Max power | 124.0 hp 92.5 kW |
| Fuel use | 7.5 gal/hour 28.4 l/hour |
| Power at rated engine speed | 115.7 hp 86.3 kW |
| Fuel use | 8.0 gal/hour 30.3 l/hour |
| Power at rated PTO speed | 122.7 hp 91.5 kW |
| Fuel use | 7.4 gal/hour 28.0 l/hour |
| Drawbar performance | |
| Max power | 100.2 hp 74.7 kW |
| Gear 1LC used for power test. | |
| Max pull | 12,165 lbs 5518 kg |
| Gear 1TD used for pull test. | |
| OCED Tractor Test 2195 | |||
| |||
| OCED Tractor Test 2195 | |
| Diesel CVT 4WD February 2004 - April 2004, Link: OCED Tractor Test 2195 file | |
| PTO performance | |
| Max power | 125.7 hp 93.7 kW |
| Fuel use | 7.8 gal/hour 29.5 l/hour |
| Power at rated engine speed | 116.3 hp 86.7 kW |
| Fuel use | 8.0 gal/hour 30.3 l/hour |
| Power at rated PTO speed | 124.6 hp 92.9 kW |
| Fuel use | 8.0 gal/hour 30.3 l/hour |
| Drawbar performance | |
| Max power | 100.4 hp 74.9 kW |
| Fuel use | 8.0 gal/hour 30.3 l/hour |
| Pull at 7.4 KPH | |
| Max pull | 14,690 lbs 6663 kg |
| Pull at 4.0 KPH | |
