Tractors > John Deere > 9300T

John Deere 9300T



John Deere 9300T tractor photo
2000 - 2001
9000 Series
Agricultural Crawler tractor
Series map:
9300T
9400T
383.9hp*
425.0hp
Production
ManufacturerJohn Deere
Agricultural Crawler tractor
Built in Waterloo, Iowa, USA
Variants
9300wheeled tractor
9300Tcrawler
John Deere 9300T Engine
John Deere 12.5L 6-cyl diesel
Engine details ...
John Deere 9300T Transmission
24-speed
Transmission details ...
John Deere 9300T Power
Drawbar (tested)304.9 hp
227.4 kW
PTO (tested)345.5 hp
257.6 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringelectro-hydraulic
Wet disc brakes
Photos
No photos of the John Deere 9300T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeIII,IV
Power Take-off (PTO)
Rear PTO Type1000
Dimensions & Tracks
Weight42,090 lbs
19092 kg
Tracks
Full dimensions and tracks ...
References
9300T references literature
9000/9000T Series Tractors Product Information Handbook published in 1999, by John Deere
