CaseIH Puma 165
|
|
| Production | |
| Manufacturer | CaseIH |
| Row-Crop tractor | |
| Factories | Basildon, England |
| St. Valentin, Austria | |
| Original price | $123,515 (2010) |
| CaseIH Puma 165 Engine | |
| CNH 6.7L 6-cyl diesel | |
 Engine details ... |
| CaseIH Puma 165 Transmissions | |
| 17-speed full power shift | |
| 18-speed full power shift | |
| 19-speed full power shift | |
| continuously variable transmission (CVT) | |
 Transmission details ... |
| CaseIH Puma 165 Power | |
| Engine | 165 hp 123.0 kW |
| PTO (claimed) | 135 hp 100.7 kW |
| Drawbar (tested) | 107.0 hp 79.8 kW |
| PTO (tested) | 163.2 hp 121.7 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Steering | hydrostatic power |
| Differential hydraulic wet disc brakes | |
| Trailer brakes | hydraulic optional |
| Cab standard. | |
| Photos | |
 | |
 CaseIH Puma 165 photos... | |
| Capacity | |
| Fuel | 116 gal (early) 439.1 L |
| 107 gal (late) 405.0 L | |
| Hydraulic system | 26.5 gal 100.3 L |
| Hydraulics | |
| Type | pressure flow compensating (PFC) |
| Capacity | 26.5 gal 100.3 L |
| Valves | 3 to 5 |
| Pump flow | 31.7 gpm (powershift std.) 120.0 lpm |
| 39.6 gpm (CVT, ps-opt.) 149.9 lpm | |
| 45 gpm (CVT opt.) 170.3 lpm | |
| Total flow | 48.7 gpm (powershift std.) 184.3 lpm |
| 56.6 gpm (CVT, ps-opt.) 214.2 lpm | |
| 62 gpm (CVT opt.) 234.7 lpm | |
| Steering flow | 17 gpm 64.3 lpm |
| Tractor hitch | |
| Rear Type | II/IIIN |
| Rear lift (at ends) | 12,787 lbs 5800 kg |
| 15,873 lbs (optional) 7199 kg | |
| Rear lift (at 24"/610mm) | 10,900 lbs 4944 kg |
| 13,600 lbs (optional) 6168 kg | |
| Front Hitch | optional |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1-3/8) |
| 1000 (1-3/4) | |
| 1000/1000E (with CVT) | |
| Front PTO | optional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 113.6 inches 288 cm |
| Weight | 15708 to 17725 pounds |
| Front tire | 16.9R30 |
| Rear tire | 20.8R42 |
 Full dimensions and tires ... | |
| CaseIH Puma 165 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 150 |
| Battery CCA | 1300 |
| Battery volts | 12 |
| References | |
 | |
| Puma Series Tractors published in 2007, by CaseIH |
