Series map:
8110
8130
100.0hp
120.0hp
| Transmission options |
| 18-speed synchronized |
| 36-speed partial power shift |
| 24-speed synchronized with creeper |
| 48-speed partial power shift |
| Transmission |
| Type | synchronized
|
| Gears | 18 forward and 6 reverse
|
| Six gears (1-6) in three ranges (L/M/V) plus reverse range. In some areas sixth gears was not available, providing a total of 15 forward and 5 reverse. |
| Speeds |
|
| Transmission |
| Transmission | Steyr-Matic
|
| Type | partial power shift
|
| Gears | 36 forward and 12 reverse
|
| Transmission |
| Type | synchronized with creeper
|
| Gears | 24 forward and 6 reverse
|
| Additional creeper range (K) added to the basic transmission. |
| Speeds |
|
| Transmission |
| Transmission | Steyr-Matic
|
| Type | partial power shift
|
| Gears | 48 forward and 12 reverse
|
