Montana R3644
| | 2007 - 2010 |
| R Series | | Compact Utility tractor | | LS built |
|
| Production |
| Distributor | Montana
|
| Manufacturer | LS
|
| Compact Utility tractor |
| Montana R3644 Power |
| Engine | 38.5 hp
28.7 kW
|
| Gear PTO (claimed) | 31 hp
23.1 kW
|
| Hydro PTO (claimed) | 29 hp
21.6 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post ROPS. |
| Photos |
| No photos of the Montana R3644 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 2417 psi
166.7 bar
|
| Valves | 2
|
| Pump flow | 8.1 gpm
30.7 lpm
|
| Steering flow | 3.592 gpm
13.6 lpm
|
| Steering press. | 1706 psi
117.6 bar
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 2619 lbs
1187 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| Mid PTO | optional
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 50
|
| Battery volts | 12
|
