TYM T400
| Production |
| Manufacturer | TYM
|
| TYM T400 Power |
| Engine | 43 hp
32.1 kW
|
| PTO (claimed) | 36.5 hp
27.2 kW
|
| Mechanical |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Photos |
| No photos of the TYM T400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 9.25 gal
35.0 L
|
| Hydraulic system | 9 gal
34.1 L
|
| Hydraulics |
| Capacity | 9 gal
34.1 L
|
| Valves | 2 rear, 1 front
|
| Pump flow | 8.4 gpm
31.8 lpm
|
| Total flow | 11.78 gpm
44.6 lpm
|
| Tractor hitch |
| Rear Type | I/II
|
| Rear lift (at ends) | 2,865 lbs
1299 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Electrical |
| Charging amps | 50
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on March 7, 2014 |
