AGCO ST30
| | 2001 - 2004 |
| ST Series | | Compact Utility tractor | | Iseki built |
|
| Production |
| Distributor | AGCO
|
| Manufacturer | Iseki
|
| Compact Utility tractor |
| Built in Matsuyama, Japan |
| Variants |
| 1235 | similar Massey Ferguson model
|
| AGCO ST30 Power |
| Engine (gross) | 30.3 hp
22.6 kW
|
| Engine (net) | 29.1 hp
21.7 kW
|
| Gear PTO (claimed) | 24.5 hp
18.3 kW
|
| Hydro PTO (claimed) | 22.3 hp
16.6 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | spur gear
|
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. |
| Capacity |
| Fuel | 6.1 gal
23.1 L
|
| Hydraulic system | 3.2 gal
12.1 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 3.2 gal
12.1 L
|
| Pressure | 2130 psi
146.9 bar
|
| Pump flow | 6.0 gpm
22.7 lpm
|
| Total flow | 8.5 gpm
32.2 lpm
|
| Steering flow | 2.5 gpm
9.5 lpm
|
| Steering press. | 1707 psi
117.7 bar
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| | draft control OptOptional
|
| Rear lift (at ends) | 1984 lbs
899 kg
|
| Rear lift (at 24"/610mm) | 1201 lbs
544 kg
|
| Rear Arms | fixed link ends with turn-buckle stabilizers
|
| Power Take-off (PTO) |
| Rear PTO | live (gear)
|
| | independent (hydro)
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2327
|
| Mid PTO | live OptOptional
|
| Clutch | dry disc
|
| Mid PTO Type | SAE 15 1.0
|
| Engine RPM | 2000@2482
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery CCA | 582
|
| Battery volts | 12
|
| References |
 |
| Compact Tractors published in 2000, by AGCO |
| ST Series published in 2001, by AGCO |
| ST Series Compact Tractors published in 2002, by AGCO |
| ST Series Compact Tractors published in 2001, by AGCO* |
| *Publication contains known errors. |
