AGCO ST28A
|
|
| Production | |
| Distributor | AGCO |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Built in Matsuyama, Japan | |
| AGCO ST28A Engine | |
| Iseki 1.5L 3-cyl diesel | |
 Engine details ... |
| AGCO ST28A Transmissions | |
| hydrostatic | |
| 9-speed | |
 Transmission details ... |
| AGCO ST28A Power | |
| Engine (gross) | 28.4 hp 21.2 kW |
| Hydro PTO (claimed) | 22.3 hp 16.6 kW |
| Gear PTO (claimed) | 24.5 hp 18.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the AGCO ST28A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 7.4 gpm 28.0 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 2425 lbs 1099 kg |
| Rear lift (at 24"/610mm) | 1610 lbs 730 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission (gear) |
| independent (hydrostatic) | |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent OptOptional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 65.5 inches 166 cm |
| Weight | 2205 lbs 1000 kg |
 Full dimensions and tires ... | |
| AGCO ST28A attachments | |
| 60" mid-mount mower deck | |
| 72" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| ST Series published in 2004, by AGCO* | |
| *Publication contains known errors. |
