John Deere 7710


John Deere 7710 tractor photo
1997 - 2003
7010 Series
Row-Crop tractor
Series map:
7610
7710
7810
140.0hp
155.0hp
175.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
John Deere 7710 Engine
John Deere 8.1L 6-cyl diesel
Engine details ...
John Deere 7710 Transmissions
16-speed partial power shift
19-speed full power shift
Infinitely Variable Transmission (IVT)
20-speed partial power shift
Transmission details ...
John Deere 7710 Power
Engine155 hp
115.6 kW
PTO (claimed)135 hp
100.7 kW
Drawbar (tested)123.87 hp
92.4 kW
PTO (tested)151.46 hp
112.9 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Cab standard.
Capacity
Fuel71.5 gal (ROPS)
270.6 L
 91 gal (cab)
344.4 L
Front axle15.2 qts
14.4 L
Front hubs2 qts
1.9 L
Hydraulics
Typeclosed center pressure flow compensated (PFC)
Pressure2900 psi
200.0 bar
Valves2 to 5
SCV flow26 gpm
98.4 lpm
Tractor hitch
Rear TypeIIIN/II
Rear lift8925 lbs
4048 kg
 10050 lbsOptOptional
4558 kg
Front HitchIIIN/II OptOptional
Front lift7700 lbs
3492 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet discs
Rear PTO Type540/1000 (1.375)
Engine RPM540@2100
 1000@2100
Dimensions & Tires
2WD Wheelbase114.4 inches
290 cm
4WD Wheelbase110.2 inches
279 cm
Weight12352 to 15070 pounds
Front tire11.00-16
2WD Rear tire18.4-38
Full dimensions and tires ...
7710 Serial Number Location
John Deere 7710 serial number location
Serial number plate on the right side of the tractor frame, above the front axle.
7710 Serial Numbers
19971001
199810001
199920001
200030001
200150001
200270001
200380001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps140
Batteries2
Battery CCA925
Battery volts12
References
7710 references literature
7000 TEN Series Tractors and 7405 Advantage Series Tractors Product Information Handbook published in 1998, by John Deere
7000 TEN Series Tractors and 7405 Advantage Series Tractors Product Information Handbook published in 1999, by John Deere
New 95- to 150-HP 7000 TEN Series Tractors published in 1996, by John Deere
7000 TEN Series published in 1999, by John Deere
New 7000 TEN Series Tractors - Feel The Earth Move published in 1996, by John Deere
