Mitsubishi MT200
| | 2000 - 2007 |
| MT Series | | Compact Utility tractor |
|
Series map:
MT200
MT260
14.9kw
19.4kw
| Production |
| Manufacturer | Mitsubishi
|
| Compact Utility tractor |
| Mitsubishi MT200 Power |
| Engine | 20 hp
14.9 kW
|
| PTO (claimed) | 17.5 hp
13.0 kW
|
| Mechanical |
| Drive | 4x2 2WD
|
| | 4x4 MFWD 4WD (MT200D)
|
| Steering | hydrostatic power
|
| Drum brakes |
| Two-post ROPS. |
| Photos |
| No photos of the Mitsubishi MT200 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 2134 psi
147.1 bar
|
| Pump flow | 5.84 gpm
22.1 lpm
|
| Steering flow | 3.41 gpm
12.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control, draft control optional
|
| Rear lift (at ends) | 1400 lbs
635 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Rear PTO Type | 540/1000 (1.375)
|
| Mid PTO | optional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
