Deutz-Allis 6260
| | 1986 - 1990 |
| 6200 Series | | Utility tractor |
|
Series map:
6250
6260
6265
54.0hp
61.0hp
70.0hp
| Production |
| Manufacturer | Deutz-Allis
|
| Utility tractor |
| Built in Germany |
| Deutz-Allis 6260 Power |
| Engine | 61 hp
45.5 kW
|
| PTO (claimed) | 57 hp
42.5 kW
|
| Drawbar (tested) | 50.22 hp
37.4 kW
|
| PTO (tested) | 57.09 hp
42.6 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| ROPS Brakes | mechanical disc
|
| Cab Brakes | hydraulic disc
|
| Four-post ROPS. StarCab optional. |
| Photos |
| No photos of the Deutz-Allis 6260 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| ROPS Fuel | 20 gal
75.7 L
|
| Cab Fuel | 12 gal
45.4 L
|
| Hydraulic system | 4 gal
15.1 L
|
| | 7.5 galOptOptional
28.4 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 4 gal
15.1 L
|
| | 7.5 galOptOptional
28.4 L
|
| Pressure | 2538 psi
175.0 bar
|
| Valves | 1 to 3
|
| Pump flow | 5291 gpm
20026.4 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift (at ends) | 5291 lbs
2399 kg
|
| Front Hitch | II
|
| Front lift | 2205 lbs
1000 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Front PTO | independent
|
| Front PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| 6240/6250/6260 published in 1985, by Deutz-Allis |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on November 21, 2018 |
