New Holland TM165


New Holland TM165 tractor photo
2000 - 2002
TM Series
Row-Crop tractor
Series map:
TM150
TM165
150.0hp
165.0hp
Production
ManufacturerNew Holland
Row-Crop tractor
Built in Basildon, England
New Holland TM165 Engine
New Holland 7.5L 6-cyl diesel
Engine details ...
New Holland TM165 Transmissions
18-speed power shift
18-speed full power shift
Transmission details ...
New Holland TM165 Power
Engine165 hp
123.0 kW
PTO (claimed)135 hp
100.7 kW
Drawbar (tested)125.0 hp
93.2 kW
PTO (tested)148.3 hp
110.6 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard.
Photos
No photos of the New Holland TM165 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel85 gal
321.7 L
Hydraulic system26.5 gal
100.3 L
Hydraulics
Typeclosed-center load sensing (CCLS)
Capacity26.5 gal
100.3 L
Pressure2750 psi
189.6 bar
Rear valves4 (max)
Mid valves4 (max)
Pump flow28 gpm
106.0 lpm
Steering flow16.4 gpm
62.1 lpm
Tractor hitch
Rear TypeIII/II
Controlelectronic lower-link draft sensing
Rear lift11690 lbs
5302 kg
Front HitchII
Front lift7208 lbs
3269 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
 540/540E/1000 *Optional. Only available in select markets.
Engine RPM540@1970
 540E@1546
 1000@2120
Dimensions & Tires
2WD Wheelbase108.1 inches
274 cm
4WD Wheelbase107.2 inches
272 cm
SuperSteer Wheelbase113.4 inches
288 cm
Terraglide Wheelbase109.6 inches
278 cm
Weight11023 to 14455 pounds
Front tire480/70R-28
Rear tire580/70R-38
Full dimensions and tires ...
TM165 Serial Numbers
200013443B
2001155247B
2002173895B

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Batteries2
Battery CCA900
Battery volts12
References
TM165 references literature
92 to 135 PTO hp Tractors published in 2001, by New Holland
Operator's Manual TM115, TM125, TM135, TM150 and TM160 Tractors (604.53.261.00) published in 1999
