New Holland TM135



New Holland TM135 tractor photo
2000 - 2002
TM Series
Row-Crop tractor
Series map:
TM125
TM135
TM150
125.0hp
135.0hp
150.0hp
Production
ManufacturerNew Holland
Row-Crop tractor
Built in Basildon, England
New Holland TM135 Engine
New Holland 7.5L 6-cyl diesel
Engine details ...
New Holland TM135 Transmissions
18-speed power shift
24-speed two-speed power shift
Transmission details ...
New Holland TM135 Power
Engine135 hp
100.7 kW
PTO (claimed)110 hp
82.0 kW
Drawbar (tested)98.2 hp
73.2 kW
PTO (tested)118.7 hp
88.5 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard.
Photos
No photos of the New Holland TM135 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel58 gal
219.5 L
Hydraulic system23.75 gal
89.9 L
Hydraulics
Typeclosed-center load sensing (CCLS)
Capacity23.75 gal
89.9 L
Pressure2750 psi
189.6 bar
Rear valves4 (max)
Mid valves4 (max)
Pump flow28 gpm
106.0 lpm
Steering flow15.5 gpm
58.7 lpm
Tractor hitch
Rear TypeII
Controlelectronic lower-link draft sensing
Rear lift11690 lbs
5302 kg
Front HitchII
Front lift7208 lbs
3269 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
 540/540E/1000 *Optional. Only available in select markets.
Engine RPM540@1970
 540E@1546
 1000@2120
Dimensions & Tires
2WD Wheelbase108.1 inches
274 cm
4WD Wheelbase107.2 inches
272 cm
SuperSteer Wheelbase113.4 inches
288 cm
Terraglide Wheelbase109.6 inches
278 cm
Weight10472 to 13515 pounds
Front tire480/70R-28
Rear tire580/70R-38
Full dimensions and tires ...
New Holland TM135 attachments
front-end loader
Attachment details ...
TM135 Serial Numbers
200013443B
2001155247B
2002173895B

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Batteries2
Battery CCA900
Battery volts12
References
TM135 references literature
92 to 135 PTO hp Tractors published in 2001, by New Holland
Operator's Manual TM115, TM125, TM135, TM150 and TM160 Tractors (604.53.261.00) published in 1999
