New Holland TG230
|
|
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Row-Crop tractor | |
| Built in Racine, Wisconsin, USA | |
| Variants | |
| MX230 | similar CaseIH model |
| New Holland TG230 Engine | |
| CDC 8.3L 6-cyl diesel | |
| Fuel tank | 130 gal 492.1 L |
| 160 galOptOptional 605.6 L | |
 Engine details ... | |
| New Holland TG230 Transmissions | |
| 18-speed full power shift | |
| 24-speed creeper | |
 Transmission details ... |
| New Holland TG230 Power | |
| Engine | 230 hp 171.5 kW |
| PTO (claimed) | 190 hp 141.7 kW |
| Drawbar (tested) | 163.29 hp 121.8 kW |
| PTO (tested) | 216.31 hp 161.3 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the New Holland TG230 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing |
| Pressure | 2930 psi 202.0 bar |
| Valves | 3 to 5 |
| Pump flow | 38.6 gpm 146.1 lpm |
| 68 gpm*With optional Mega Flow 257.4 lpm | |
| Tractor hitch | |
| Rear Type | III/IIIN |
| Control | position and electronic draft control |
| Rear lift (at 24"/610mm) | 13960 lbs 6332 kg |
| 15970 lbsOptOptional 7243 kg | |
| 14780 lbs (Europe) 6704 kg | |
| Front Hitch | IIIN OptOptional |
| Front lift (at 24"/610mm) | 9185 lbs 4166 kg |
| 9450 lbs (SuperSteer) 4286 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 1000 (1.75) |
| 540/1000 (1.375)OptOptional | |
| Engine RPM | 540@2000 |
| 1000@2000 | |
| Dimensions & Tires | |
| Wheelbase | 121.2 inches 307 cm |
| 129.3 inches (SuperSteer) 328 cm | |
| Weight | 19582 to 20382 pounds |
| Front tire | 16.9R30 |
| Rear tire | 20.8R42 |
 Full dimensions and tires ... | |
| New Holland TG230 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 135 |
| Batteries | 2 |
| Battery CCA | 1000 |
| Battery volts | 12 |
| Battery Group | 31 |
| References | |
 | |
| TG Tractors published in 2002, by New Holland | |
| TG Tractors published in 2003, by New Holland |
