New Holland TC29


New Holland TC29 tractor photo
1999 - 2003
Boomer TC Series
Compact Utility tractor
Series map:
TC25
TC29
TC33
25.0hp
29.0hp
33.0hp
Production
ManufacturerNew Holland
Compact Utility tractor
Original price was $16,500 in 2000
Variants
TC29gear
TC29Dhydrostatic
D29similar CaseIH model
DX29similar CaseIH model
New Holland TC29 Engine
Shibaura 1.3L 3-cyl diesel
Fuel tank7.3 gal
27.6 L
Engine details ...
New Holland TC29 Power
Engine (gross)29 hp
21.6 kW
Engine (net)27.4 hp
20.4 kW
Gear PTO (claimed)25 hp
18.6 kW
Hydro PTO (claimed)23.6 hp
17.6 kW
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post ROPS. Folding ROPS on hydrostatic (D) model.
Hydraulics
Typeopen center
Pressure2133 psi
147.1 bar
Gear Pump flow6.6 gpm
25.0 lpm
Hydro Pump flow7.6 gpm
28.8 lpm
Gear Total flow10.1 gpm
38.2 lpm
Hydro Total flow12.7 gpm
48.1 lpm
Gear Steering flow3.5 gpm
13.2 lpm
Hydro Steering flow5.1 gpm
19.3 lpm
Tractor hitch
Rear TypeI
Rear lift (at 24"/610mm)1635 lbs
741 kg
Power Take-off (PTO)
Gear Rear PTOtransmission
Hydro Rear PTOlive
Rear PTO Type540
Mid PTOoptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase63 inches
160 cm
SuperSteer Wheelbase72 inches
182 cm
Weight2474 to 2588 pounds
Front tire5.50-16
Rear tire11.2-24
Full dimensions and tires ...
New Holland TC29 attachments
60" mid-mount mower deck
72" mid-mount mower deck
snowblower
blade
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
TC29 references literature
Boomer Compact Tractors published in 1999, by New Holland*
BOOMER Compact Tractors published in 2003, by New Holland
*Publication contains known errors.
