Allis Chalmers HD14 Transmission


Allis Chalmers HD14 tractor photo
1939 - 1947
Series map:
HD14
161.1hp*
*Estimated engine power for comparison only.
Transmission options
6-speed sliding gear
3-speed torque converter
Transmission
Typesliding gear
Gears6 forward and 2 reverse
Oil capacity40 qts
37.9 L
Speeds
HD14  sliding gear speeds
Transmission
Typetorque converter
Gears3 forward and 1 reverse
Speeds
HD14  torque converter speeds
