Allis Chalmers L Tests
|
|
| Tractor Tests | |
| NTTL 200: gasoline 6-speed crawler | |
| NTTL 287: diesel 6-speed crawler | |
| NTTL 338: gasoline 6-speed crawler |
| Nebraska Tractor Test 200 | |||
| |||
| Nebraska Tractor Test 200 | |
| Gasoline 6-speed crawler March 17 - April 11, 1932 Link: Nebraska Tractor Test 200 file | |
| Belt power (max) | 91.93 hp 68.6 kW |
| Belt fuel use (max) | 10.9 gal/hour 41.3 l/hour |
| Drawbar performance | |
| Max power | 76.01 hp 56.7 kW |
| Gear 2 used for power test. | |
| Max pull | 15086 lbs 6843 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 287 | |||
| |||
| Nebraska Tractor Test 287 | |
| Diesel 6-speed crawler September 9 - 22, 1937 Link: Nebraska Tractor Test 287 file | |
| Belt power (max) | 91.56 hp 68.3 kW |
| Belt fuel use (max) | 7.3 gal/hour 27.6 l/hour |
| Drawbar performance | |
| Max power | 76.75 hp 57.2 kW |
| Gear 2 used for power test. | |
| Max pull | 20273 lbs 9195 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 338 | |||
| |||
| Nebraska Tractor Test 338 | |
| Gasoline 6-speed crawler November 23 - 28, 1939 Link: Nebraska Tractor Test 338 file | |
| Belt power (max) | 108.84 hp 81.2 kW |
| Belt fuel use (max) | 10.5 gal/hour 39.7 l/hour |
| Drawbar performance | |
| Max power | 91.99 hp 68.6 kW |
| Gear 2 used for power test. | |
| Max pull | 23851 lbs 10818 kg |
| Gear 1 used for pull test. | |
