Volvo T35
|
|
| Production | |
| Manufacturer | Volvo |
| Row-Crop tractor | |
| Total built | 825 |
| The Volvo T35 was the same as the Bolinder Munktell BM35, and very similar to the T36. | |
| Volvo T35 Engine | |
| Bolinder 3.4L 3-cyl diesel | |
| Fuel tank | 17.2 gal 65.1 L |
 Engine details ... | |
| Volvo T35 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Volvo T35 Power | |
| Engine | 41.9 hp 31.2 kW |
| PTO (claimed) | 37.5 hp 28.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Open operator station. |
| Photos | |
 | |
 Volvo T35 photos... | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1500 |
| Dimensions & Tires | |
| Wheelbase | 77.2 inches 196 cm |
| Weight | 5424 lbs 2460 kg |
| Front tire | 6.00x19 |
| Rear tire | 13x30 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | generator |
| Battery volts | 12 |
| References | |
 | |
| T35/36 published in 1957, by Volvo |
